What engine does the VD600-04FT4MP use?

The Volvo Penta TWD1683GE — a 16.12-liter, six-cylinder turbocharged and charge-air-cooled diesel. The TWD1683GE is the higher-output calibration of the same 16.12-liter TWD block used in the VD550-04FT4MP (TWD1682GE). Both engines share the same displacement, cylinder count, and architecture; the 1683 calibration produces 600 kWe standby and 570 kWe prime through higher fuel delivery and boost mapping. EPA Tier 4 Final and EU Stage 5 dual certification applies. The 52.8-gallon DEF tank is shared with the VD550. Rated power is available to 4,921 ft (1,500 m) at 122°F (50°C).

What controller does the VD600-04FT4MP use?

The DSE DCP7310 Digital Control Panel, with CAN Bus J1939 engine communication, digital metering, RS-485 interface, 8 programmable contact inputs, 10 contact outputs, and NFPA 110 Level 1 compatibility. The panel is cULus Listed and CE Approved with IP 65 ingress protection (with supplied gasket). A 24V battery system and battery charger are included. The 572RSL6431 alternator is the higher-output variant of the 572RSL series, stepping up from the 6429 winding used in the VD550.

How does the VD600-04FT4MP compare to the VD550-04FT4MP on the same trailer platform?

The VD550 (TWD1682GE, 550/500 kWe, 24,750 lbs, 38.3 gph, 572RSL6429) and VD600 (TWD1683GE, 600/570 kWe, 25,000 lbs, 39.6 gph, 572RSL6431) share identical 334.5 × 99.5 × 144 in trailer dimensions and the same 550-gallon fuel / 52.8-gallon DEF tanks. The difference is 250 lbs, 1.3 gph at full load, and 50 kWe standby / 70 kWe prime additional output. The VD600 prime rating of 570 kWe is a tighter margin below standby (30 kWe spread vs 50 kWe on the VD550). The two models are effectively the same deployment package at different output ceilings.

What are the fuel and DEF logistics for the VD600-04FT4MP?

The 550-gallon integral fuel tank at full standby load (39.6 gph) provides approximately 13.9 hours of runtime. At 75% load (29.9 gph), runtime extends to approximately 18.4 hours. The 52.8-gallon DEF tank typically supports 12–16 hours at full load. For 24-hour continuous deployments, one full refueling cycle and approximately one DEF refill are required. Combustion air draw is 1,801 CFM; ventilation requirement is 26,926 CFM; heat rejected to coolant is 743,820 BTU/hr; radiated heat is 716,880 BTU/hr; exhaust exits at 862°F at 3,991 CFM.

What engine does the VD600-04FT4MP use?

The Volvo Penta TWD1683GE — a 16.12-liter, six-cylinder turbocharged and charge-air-cooled diesel. The TWD1683GE is the higher-output calibration of the same 16.12-liter TWD block used in the VD550-04FT4MP (TWD1682GE). Both engines share the same displacement, cylinder count, and architecture; the 1683 calibration produces 600 kWe standby and 570 kWe prime through higher fuel delivery and boost mapping. EPA Tier 4 Final and EU Stage 5 dual certification applies. The 52.8-gallon DEF tank is shared with the VD550. Rated power is available to 4,921 ft (1,500 m) at 122°F (50°C).

What controller does the VD600-04FT4MP use?

The DSE DCP7310 Digital Control Panel, with CAN Bus J1939 engine communication, digital metering, RS-485 interface, 8 programmable contact inputs, 10 contact outputs, and NFPA 110 Level 1 compatibility. The panel is cULus Listed and CE Approved with IP 65 ingress protection (with supplied gasket). A 24V battery system and battery charger are included. The 572RSL6431 alternator is the higher-output variant of the 572RSL series, stepping up from the 6429 winding used in the VD550.

How does the VD600-04FT4MP compare to the VD550-04FT4MP on the same trailer platform?

The VD550 (TWD1682GE, 550/500 kWe, 24,750 lbs, 38.3 gph, 572RSL6429) and VD600 (TWD1683GE, 600/570 kWe, 25,000 lbs, 39.6 gph, 572RSL6431) share identical 334.5 × 99.5 × 144 in trailer dimensions and the same 550-gallon fuel / 52.8-gallon DEF tanks. The difference is 250 lbs, 1.3 gph at full load, and 50 kWe standby / 70 kWe prime additional output. The VD600 prime rating of 570 kWe is a tighter margin below standby (30 kWe spread vs 50 kWe on the VD550). The two models are effectively the same deployment package at different output ceilings.

What are the fuel and DEF logistics for the VD600-04FT4MP?

The 550-gallon integral fuel tank at full standby load (39.6 gph) provides approximately 13.9 hours of runtime. At 75% load (29.9 gph), runtime extends to approximately 18.4 hours. The 52.8-gallon DEF tank typically supports 12–16 hours at full load. For 24-hour continuous deployments, one full refueling cycle and approximately one DEF refill are required. Combustion air draw is 1,801 CFM; ventilation requirement is 26,926 CFM; heat rejected to coolant is 743,820 BTU/hr; radiated heat is 716,880 BTU/hr; exhaust exits at 862°F at 3,991 CFM.

Blue Star Power Systems · Mobile Product Line (Volvo Penta)

New

Blue Star VD600-04FT4MP

Name: Blue Star VD600-04FT4MP
Brand: Blue Star Power Systems
Availability: PreOrder

600 kW standby / 570 kW prime · Diesel · Liquid-cooled

600 kW standby / 570 kW prime Tier 4 Final / EU Stage 5 mobile trailer diesel generator built by Blue Star Power Systems. Volvo Penta TWD1683GE six-cylinder engine, 572RSL6431 alternator, DSE DCP7310 controller, 550-gallon integrated fuel tank.

Photo coming soon

Standby power: 600 kW / 570 kW prime
Voltage options: 120/208V, 277/480V
Frequency / Phase: 60 Hz · 3-phase
Engine: Volvo Penta TWD1683GE · 16.12L
EPA / Emissions: Tier 4 Final
Alternator: Leroy-Somer 572RSL6431

constructiontemporary-powerindustrialmunicipalhealthcaredata-centerpump-station

Overview#

The Blue Star VD600-04FT4MP is a 600-kilowatt standby / 570-kilowatt prime EPA Tier 4 Final / EU Stage 5 mobile trailer diesel generator powered by the Volvo Penta TWD1683GE — a 16.12-liter, six-cylinder turbocharged and charge-air-cooled engine. It is the largest model in Blue Star's Tier 4 Final mobile lineup, sharing the 334.5 × 99.5 in trailer platform with the VD550-04FT4MP but producing 600/570 kWe from the higher-calibration TWD1683GE.

Blue Star Power Systems mounts the TWD1683GE on an aluminum road trailer with a 550-gallon integral fuel tank and 52.8-gallon DEF tank, paired with a Leroy-Somer 572RSL6431 alternator and DSE DCP7310 controller. At 25,000 lbs, the VD600-04FT4MP is the heaviest unit in the Blue Star Tier 4 Final mobile product line. Three-phase only; no 600V configuration — the mobile lineup is 208V–480V.

TWD1682 vs TWD1683: Same Block, Higher Calibration#

The VD550 (TWD1682GE) and VD600 (TWD1683GE) share the same 16.12-liter Volvo Penta TWD block and physical trailer. The numerical calibration increment (1682 → 1683) reflects a higher fuel delivery and boost mapping to reach 600/570 kWe vs 550/500 kWe. From a service and logistics standpoint, the two models are nearly identical in deployment requirements. The choice between them is driven entirely by load requirement.

Prime Power Ratings at This Output Class#

The VD600-04FT4MP standby rating is 600 kWe; the prime rating is 570 kWe — a 30 kWe spread that is narrower than the 50 kWe spread on the VD550. For prime power applications (continuous variable load, unlimited hours), size to 570 kWe. The 600 kWe rating applies only to emergency standby use. Verify the application rating with the site's power engineer before finalizing the specification.

When to specify the VD600-04FT4MP#

550–600 kW three-phase emergency standby or up to 570 kW prime mobile power at large industrial, municipal, healthcare, or data center sites
Maximum output from Blue Star's Tier 4 Final mobile product line
Sites up to 4,921 ft elevation at ambient temperatures to 122°F
Applications requiring EU Stage 5 dual certification at this output level
Projects where the VD550 at 550/500 kWe is insufficient and the same 334.5 × 99.5 in trailer is acceptable

Our service experience#

The VD600-04FT4MP is the most demanding model in Blue Star's T4F mobile lineup. The TWD1683GE at 600 kWe standby / 570 kWe prime requires the full Volvo Penta TWD preventive maintenance schedule including aftertreatment system management. At 39.6 gph diesel and the associated DEF consumption rate, fuel and DEF logistics dominate operational planning on long deployments. The 334.5 in trailer length and 25,000 lb weight require permits and specialized towing in most jurisdictions. Site entry dimensions must be confirmed: the 99.5 in width exceeds standard lane width in some site configurations. Annual full-load testing at 39.6 gph is mandatory. Exhaust at 862°F and 3,991 CFM requires properly rated exhaust connections and transition hardware.

Engineering specifications

Physical

Length: 334.5 in
Width: 99.5 in
Height: 144 in
Dry weight: 25,000 lb

Acoustic

Sound @ 7m, full load: 76 dBA
Enclosure: Open

Fuel system & runtime

Integral fuel tank: 550 gal
Fuel use @ full load: 39.6 GPH
Fuel use @ 75% load: 29.9 GPH
Fuel use @ 50% load: 21.6 GPH
DEF tank: 52.8 gal

Thermal & ventilation

Heat to coolant: 743,820 BTU/hr
Heat radiated: 716,880 BTU/hr
Exhaust flow: 3,991 CFM
Exhaust temp: 862 °F
Combustion air: 1,801 CFM
Ventilation air: 26,926 CFM

Documents & downloads

Spec sheets & manuals

Spec sheet (datasheet)

Request a quote

Get pricing & lead time on the Blue Star VD600-04FT4MP

Tell us about the application — kW, voltage, application, install timeline — and we'll respond within one business day with budgetary pricing, lead time, and any sizing notes.

Request a quote →Download datasheet

Estimate runtime for the Blue Star VD600-04FT4MP

Adjust load percent and tank size to estimate runtime. Pre-filled with this model's spec where available.

Estimate runtime on this tank

Generator size

Fuel

Fuel tank capacity

gal

Load

Override full-load GPH (optional)

GPH

Estimated runtime

18.0 hours(0.8 days)

Fuel consumption ≈ 30.55 GPH at 75% load. Estimate based on industry-typical 1800 RPM standby curves (≈0.07 GPH/kW at full load). Actual consumption varies by engine, ambient temperature, fuel quality, and tuning.

Service intervals

Manufacturer-recommended intervals for the Blue Star VD600-04FT4MP under standby duty. Field intervals may differ based on load profile, ambient conditions, and fuel quality.

Oil & filter: Every 500 hours or 12 months
Coolant change: Every 6000 hours
Air filter: Every 1000 hours
Fuel filter: Every 500 hours
Major overhaul: ≈ 20,000 hours
Load bank test: Every 12 months

Common failure modes

What we've seen fail on this platform. Use as a service-planning reference, not a diagnostic — actual failure modes depend heavily on duty cycle and maintenance history.

Component	Symptom	Typical hours	Severity
DEF system (SCR catalyst)	Derate warning, NOx fault, DEF quality alert	4,380+	moderate
Turbocharger(s)	Major power loss, heavy exhaust smoke	12,000+	severe
Fuel quality / degradation	Injector fouling, hard starting	4,380+	moderate
Battery bank (24V)	Failed start, slow cranking	8,760+	minor

Frequently Asked Questions

What engine does the VD600-04FT4MP use?: The Volvo Penta TWD1683GE — a 16.12-liter, six-cylinder turbocharged and charge-air-cooled diesel. The TWD1683GE is the higher-output calibration of the same 16.12-liter TWD block used in the VD550-04FT4MP (TWD1682GE). Both engines share the same displacement, cylinder count, and architecture; the 1683 calibration produces 600 kWe standby and 570 kWe prime through higher fuel delivery and boost mapping. EPA Tier 4 Final and EU Stage 5 dual certification applies. The 52.8-gallon DEF tank is shared with the VD550. Rated power is available to 4,921 ft (1,500 m) at 122°F (50°C).
What controller does the VD600-04FT4MP use?: The DSE DCP7310 Digital Control Panel, with CAN Bus J1939 engine communication, digital metering, RS-485 interface, 8 programmable contact inputs, 10 contact outputs, and NFPA 110 Level 1 compatibility. The panel is cULus Listed and CE Approved with IP 65 ingress protection (with supplied gasket). A 24V battery system and battery charger are included. The 572RSL6431 alternator is the higher-output variant of the 572RSL series, stepping up from the 6429 winding used in the VD550.
How does the VD600-04FT4MP compare to the VD550-04FT4MP on the same trailer platform?: The VD550 (TWD1682GE, 550/500 kWe, 24,750 lbs, 38.3 gph, 572RSL6429) and VD600 (TWD1683GE, 600/570 kWe, 25,000 lbs, 39.6 gph, 572RSL6431) share identical 334.5 × 99.5 × 144 in trailer dimensions and the same 550-gallon fuel / 52.8-gallon DEF tanks. The difference is 250 lbs, 1.3 gph at full load, and 50 kWe standby / 70 kWe prime additional output. The VD600 prime rating of 570 kWe is a tighter margin below standby (30 kWe spread vs 50 kWe on the VD550). The two models are effectively the same deployment package at different output ceilings.
What are the fuel and DEF logistics for the VD600-04FT4MP?: The 550-gallon integral fuel tank at full standby load (39.6 gph) provides approximately 13.9 hours of runtime. At 75% load (29.9 gph), runtime extends to approximately 18.4 hours. The 52.8-gallon DEF tank typically supports 12–16 hours at full load. For 24-hour continuous deployments, one full refueling cycle and approximately one DEF refill are required. Combustion air draw is 1,801 CFM; ventilation requirement is 26,926 CFM; heat rejected to coolant is 743,820 BTU/hr; radiated heat is 716,880 BTU/hr; exhaust exits at 862°F at 3,991 CFM.
