Blue Star Power Systems · Diesel Product Line (Perkins)
New
Blue Star PD600-01
600 kW standby · Diesel · Liquid-cooled
600 kW Tier 2 diesel standby generator built by Blue Star Power Systems. Perkins 2806C-E18TAG3 six-cylinder engine with charge air cooling, Stamford HCI534E alternator, DSE DCP7310 controller.
The Blue Star PD600-01 is a 600-kilowatt EPA Tier 2 diesel standby generator powered by the Perkins 2806C-E18TAG3 — an 18.1-liter, six-cylinder turbocharged and charge-air-cooled engine. The PD600-01 marks the transition to Perkins' largest six-cylinder generator platform in this lineup, stepping from the 2506C (15.2L) used in the PD500 and PD550 to the 2806C-E18 (18.1L). Despite the platform change, the 150×78 in base footprint is maintained, though the OPU enclosure grows to 103 inches tall.
Blue Star Power Systems (North Mankato, Minnesota) pairs the 2806C-E18TAG3 with a Stamford HCI534E alternator — the same alternator model as the PD550-01 at 480V — and DSE DCP7310 controller. At 10,625 lbs, the PD600-01 is 750 lbs heavier than the PD550-01. The altitude deration improves to 3,281 ft (1,000 m) at 86°F (30°C), recovering from the PD550's restrictive 1,640 ft limit. The heat radiated to ambient (714,120 BTU/hr) exceeds the coolant heat rejection (627,420 BTU/hr) — an unusual thermal profile that warrants careful equipment room heat management planning.
The 2806C-E18 displaces 18.1 liters from the same six-cylinder architecture as the 2506C, with a longer stroke and larger bore. At the TAG3 calibration, it produces 600 kWe standby with a significantly lower specific output than the ceiling-stressed 2506C-E15TAG4 — which is reflected in the improved altitude deration. The exhaust temperature (1,029°F) is lower than the 1,256°F seen on the 2206D-E13 models, and the combustion air requirement (1,837 CFM) is higher, consistent with the larger displacement.
The 2806C-E18TAG3 introduces a new engine platform with different service parts than the 2506C series. Confirm parts inventory and service documentation coverage at commissioning. The unusually high heat-radiated-to-ambient value (714,120 BTU/hr vs 627,420 BTU/hr coolant rejection) means the equipment room will experience more radiant heat than at similar output levels — verify HVAC load calculations account for this. The HCI534E alternator is shared with the PD550-01, simplifying service across both models. Follow the Perkins 2800C generator series maintenance schedule.
Tell us about the application — kW, voltage, application, install timeline — and we'll respond within one business day with budgetary pricing, lead time, and any sizing notes.
Adjust load percent and tank size to estimate runtime. Pre-filled with this model's spec where available.
Estimate runtime on this tank
Estimated runtime
6.4 hours(0.3 days)
Fuel consumption ≈ 31.24 GPH at 75% load. Estimate based on industry-typical 1800 RPM standby curves (≈0.07 GPH/kW at full load). Actual consumption varies by engine, ambient temperature, fuel quality, and tuning.
Service intervals
Manufacturer-recommended intervals for the Blue Star PD600-01 under standby duty. Field intervals may differ based on load profile, ambient conditions, and fuel quality.
Oil & filter
Every 500 hours or 12 months
Coolant change
Every 6000 hours
Air filter
Every 1000 hours
Fuel filter
Every 500 hours
Major overhaul
≈ 20,000 hours
Load bank test
Every 12 months
Common failure modes
What we've seen fail on this platform. Use as a service-planning reference, not a diagnostic — actual failure modes depend heavily on duty cycle and maintenance history.
Component
Symptom
Typical hours
Severity
Turbocharger(s)
Major power loss, heavy exhaust smoke
12,000+
severe
Fuel quality / degradation
Injector fouling, hard starting
4,380+
moderate
Battery bank (24V)
Failed start, slow cranking
8,760+
minor
Frequently Asked Questions
What engine does the PD600-01 use?
The Perkins 2806C-E18TAG3 — an 18.1-liter, six-cylinder turbocharged and charge-air-cooled diesel, representing a full platform step above the 2506C series. The 2806C-E18 is Perkins' largest six-cylinder generator engine platform in this lineup, producing 600 kWe standby with the TAG3 calibration. It carries EPA Tier 2 certification for stationary emergency applications. Rated power is available up to 3,281 ft (1,000 m) at ambient temperatures to 86°F (30°C).
What controller does the PD600-01 use?
The DSE DCP7310 Digital Control Panel, with CAN Bus J1939 engine communication, digital metering, RS-485 interface, 8 programmable contact inputs, 10 contact outputs, and NFPA 110 Level 1 compatibility. The panel is cULus Listed and CE Approved with IP 65 ingress protection (with supplied gasket). A 24V battery system and 24V 5 Amp battery charger are standard.
How does the PD600-01 compare to the PD550-01 and PD750-01?
The PD550-01 uses the 2506C-E15TAG4 (15.2L) on the same 150×78 in footprint at 9,875 lbs; the PD600-01 steps to the 2806C-E18TAG3 (18.1L) at 10,625 lbs and a taller 103 in OPU height — a platform change with a larger engine. The altitude deration improves from 1,640 ft (PD550) to 3,281 ft (PD600). The PD750-01 uses the twin-turbocharged 2806C-E18TTAG7 on the same platform at 12,200 lbs and 108 in OPU height, producing 750 kWe with a tighter 1,640 ft altitude rating.
What are the ventilation and thermal requirements for the PD600-01?
The PD600-01 requires 30,106 CFM of radiator cooling airflow. Combustion air draw is 1,837 CFM. Heat rejected to the coolant circuit is 627,420 BTU/hr; heat radiated to ambient is 714,120 BTU/hr — notably higher than the coolant rejection, indicating significant surface-radiated heat at this output level. Exhaust exits at 1,029°F at 4,982 CFM. For fuel planning: at full load (40.5 gph), a 1,000-gallon tank provides approximately 25 hours of runtime. The 24-hour fuel tank option provides 1,000 gallons.
